PE-Xa Pipe ISO15875
PE-Xa pipe is a type of cross-linking polyethylene pipe made by peroxide method , also known as PE-Xa pipe , Pexa pipe etc.
Description
PE-Xa ISO 15875
PE-Xa pipe is a type of cross-linking polyethylene pipe made by peroxide method , also known as PE-Xa pipe , Pexa pipe etc .By cross-linking (X) the polyethylene (PE ), It greatly improves the pressure resistance and the heat resistance of the pipe and it also improves the long-term strength of the pipe efficiently.
Feather
Main material：100% Virgin LG188 / Lotte 8100GX
Production standard ： ISO15875-2:2003 (PE-Xa ISO 15875）
Package : DN 16-32 100m/ 200m / 300m per roll
DN 16-50 3m / 4m / 6m per length
Roll length can be customized according to requirements.
|
CODE |
S SERIES |
SIZE |
|
HDXA001 |
S5 |
16×1.8 |
|
HDXA002 |
S5 |
20×1.9 |
|
HDXA003 |
S5 |
20×2.0 |
|
HDXA004 |
S5 |
25×2.3 |
|
HDXA005 |
S5 |
32×2.9 |
|
HDXA006 |
S5 |
40×3.7 |
|
HDXA007 |
S5 |
50×3.6 |
|
HDXA008 |
S4 |
16×2.0 |
|
HDXA009 |
S4 |
20×2.3 |
|
HDXA010 |
S4 |
25×2.8 |
|
HDXA011 |
S4 |
32×3.6 |
|
HDXA012 |
S3.2 |
16×2.2 |
|
HDXA013 |
S3.2 |
20×2.8 |
|
HDXA 014 |
S3.2 |
25×3.5 |
|
HDXA015 |
S3.2 |
32×4.4 |
Data
|
Density |
0.951 |
g/cm³ |
|
Thermal conductivity |
0.4 |
W/m▪K |
|
VICAT Softening temperature |
130-132 |
℃ |
|
Maximum temperature of function |
110 |
℃ |
|
Coefficient of linear thermal expansion |
0.15 |
Mm/m°K |
Benefits
1 Excellent heat resistance , the safe working temperature is -40℃ to 95℃.
2 Excellent pressure resistance and creep deformation resistance.
3 Healthy and non-toxic , can be used for pipes system of pure water and drinking water.
4 Corrosion-resistant , abrasion resistant and electrical insulation.
5 Unique thermal memory , Pex pipe can be bent , twisted or crushed , and it will return to its original shape by suitable means.
